Note: This window comes with a reversible clamp ring that can be installed with 3/4" or 1-1/8" wall framing full depths.
The VWD (OVR-AW4015) Overlander Awning Bunk Window can be installed on any Van and is a popular option for Camper Vans. So named "awning bunk windows", they are typically installed on the upper portion of the camper van, creating a bunk or sleeping area. These windows are designed to provide both ventilation and privacy, making them a popular choice for those living the van life.
Features
- Universal Fit
- Color = Solar Privacy Glass
- UV Rating = 17%
- Installation Type = Clamp Ring
- Mfg Country = China
- Mfg Warranty = 1 Year
- Measurements
- Bunk Window Outer Dimensions: 41" X 16"
- Bunk Window Cut-Out Dimensions: 40" X 15"
- Vent Opening Size 37-5/8" x 12-3/8"
- Clamp Ring Wall Depth: 3/4" or 1-1/8"
- Foam Seal Included
Note: This window will only install on flat walls or low curve radius vehicles such as the 2007+ Mercedes Sprinter, 2014+ Ram ProMaster, and 2015+ Ford Transits. This will not work with older Chevy and Ford models with deeper curve side window panels.
| Part/SKU | Exterior (WxH) | Interior (WxH) | Screen Opening (WxH) | Clamp Ring Depth |
| OVR3009 | 31-5/16" x 10-3/16" | 30" x 9" | 12-3/4" x 5-7/8" | 1/8" |
| OVR3310 | 35-5/16" X 11-3/16" | 33" X 10" | 14-15/16" X 7-9/16" | 1/8" |
| OVR3511 | 36-3/4" x 13-1/8" | 35-7/16" x 11-7/8 | 16" x 9-3/8"/8" | 1/8" |
| OVR4015 | 41-5/16" X 16-5/16" | 40" X 15" | 17-13/16" x 11-7/8" | 1/8" |
