VWD Universal Overlander Awning Window 36-1/2" W X 16" H (AW3515)
Couldn't load pickup availability
Club members receive 5% off every order, access to expert product consultations & exclusive content. Learn more
Note: This window comes with a reversible clamp ring that can be installed with 3/4" or 1-1/8" wall framing full depths.
Upgrade your camper van with the VWD Overlander Series Awning Van Bunk Window. This versatile and high-quality window is designed to fit most camper vans and conversions. With its solar privacy glass and 2-stage opening feature, you can enjoy a refreshing cross breeze and unobstructed view of the outdoors. The 36-1/2" X 16" measurements and clamp ring installation type make it easy to install and enhance the functionality and aesthetics of your van.
Features
- Universal Fit
- Shade / Screen Combination Included
- Color = Solar Privacy Glass
- UV Rating = 17%
- Installation Type = Clamp Ring
- Mfg Country = China
- Mfg Warranty = 1 Year
- Measurements
- Bunk Window Outer Dimensions: 36-1/2" X 16"
- Bunk Window Cut-Out Dimensions: 35-3/8" X 15"
- Vent Opening Size 33" x 12-3/8"
- Clamp Ring Wall Depth: 3/4" or 1-1/8"
- Foam Seal Included
Note: This window will only install on flat walls or low curve radius vehicles such as the 2007+ Mercedes Sprinter, 2014+ Ram ProMaster, and 2015+ Ford Transits. This will not work with older Chevy and Ford models with deeper curve side window panels.
| OVERLANDER SERIES SPECS | ||||
| Part/SKU | Exterior (WxH) | Interior (WxH) | Screen Opening (WxH) | Clamp Ring Depth |
| OVR3009 | 31-5/16" x 10-3/16" | 30" x 9" | 12-3/4" x 5-7/8" | 1/8" |
| OVR3310 | 35-5/16" X 11-3/16" | 33" X 10" | 14-15/16" X 7-9/16" | 1/8" |
| OVR3511 | 36-3/4" x 13-1/8" | 35-7/16" x 11-7/8 | 16" x 9-3/8"/8" | 1/8" |
| OVR4015 | 41-5/16" X 16-5/16" | 40" X 15" | 17-13/16" x 11-7/8" | 1/8" |
