Van Compass 2023+ Mercedes Sprinter 2500 - Opti-Rate Striker AWD 2" Complete Lift Kit (Single Rear Wheel)

$3,931.75

Shipping calculated at checkout.

JOIN VAN LAND CLUB

Club members receive 5% off every order, access to expert product consultations & exclusive content. Learn more

Part#
VCMP-7219-OPTI

Need a lift kit upgrade for your Mercedes Sprinter Mercedes Sprinter (2023+ 2500)? The¬†Van Compass 2023+ Mercedes Sprinter 2500 - Opti-Rate Striker AWD 2" Complete Lift Kit (Single Rear Wheel)¬†is built to take your adventure van deeper into rugged backcountry landscapes with confidence and control. Designed specifically for the AWD Sprinter platform, this lift kit maximizes ground clearance, tire fitment, and off-road performance while preserving factory ride dynamics.

At the heart of the system is a combination of precisely machined and welded spacers that reposition the front subframe, allowing the CVs, tie rods, and control arms to cycle properly within Mercedes‚Äô original geometry range. This careful design ensures smooth operation, durability, and reliability, even under harsh off-road conditions.

In the rear, the innovative Opti-Rate leaf spring pack is paired with a 2" lift block, longer sway bar links, shock relocation brackets, and bump stop spacers. The Opti-Rate springs allow the end-user to fine-tune spring rate and ride height based on van weight and build specifications. They are optimized for heavily built vans in the 9,000‚Äì10,000 lb range and above, making this kit ideal for upgraded Storyteller Overlands, Revels, 170 EXT vans with heavy interior build-outs, or vans carrying additional rear axle loads like door carriers, hitch racks, and trailers.

With proper wheel offset and fender trimming, the Opti-Rate Striker AWD kit allows for fitment of up to a 35 x 12.50 tire, giving your van a significant increase in traction, ground clearance, and overall trail capability.

NOTE:¬†With this lift kit, tires up to 35" diameter and 12.5" width can fit. Trimming of the fender liner and mud flap is required.

Key Features

Fits 2023+ Mercedes Sprinter AWD 2500 (Single Rear Wheel) vans only
Front subframe repositioning preserves factory CV, tie rod, and control arm geometry
Opti-Rate rear leaf spring pack for adjustable ride height and spring rate
2" rear lift block, longer sway bar links, shock relocation brackets, and bump stop spacers included
Optimized for vans in the 9,000‚Äì10,000+ lb weight range
Supports vans carrying heavy rear axle loads (door carriers, hitch racks, trailers)
Allows fitment of 35 x 12.50 tires with proper wheel offset and fender trimming
Significantly increases ground clearance and off-road traction
Carefully engineered for minimal compromise to factory ride and handling

What's Included?

Front 2" strut spacers
Front 2" subframe drop spacers
Engine and transmission mount 2" lift spacers
Front differential cam bolt kit
CNC Machined 2" steering shaft extension
Low pressure power steering hose extension
Front brake line relocation brackets
Opti-Rate Rear leaf spring pack
2" rear lift block
Extended rear sway bar links
Rear lower shock relocation brackets
Rear bump stop drop brackets
Wind assist or headlight leveling sensor bracket
All necessary hardware and detailed instructions

Fitment Guide

MODEL:¬†SPRINTER 2500

YEAR:¬†2013-PRESENT

DRIVE TYPE:¬†4X4

>>COMPLETE WHEEL AND TIRE FITMENT GUIDE<<

>>DON'T KNOW YOUR VANS WEIGHT?¬†USE THE CAT SCALE LOCATOR<<

NOTE:¬†With this lift kit, tires up to 35" diameter and 12.5" width can fit. Trimming of the fender liner and mud flap is required.

Recommended Wheel Size:¬†17" x 8.5", +45mm offset
