The ARB Twin Motor Onboard 12V Air Compressor (CKMTA12) is designed to fill the market need for a compact sized yet high-volume compressed air source to suit the high volume airflow needs of most air powered tools, and also to suit the actuation and control needs of the ARB Air Locker , and the harsh and demanding environment of the ARB Air Locker user.
Key Features: ARB Twin Motor Onboard 12V Air Compressor (CKMTA12)
- Designed for inflating Tires and Air Locker activation when used in conjunction with optional accessories
- On-board model available in either a 12V or 24V configuration
- Suitable for many air tools when used in conjunction with a 4L air tank (optional with on-board models)
- 100% duty cycle
- Sealed for moisture and dust resistance
- Hard anodized cylinder bores for reduced friction
- Teflon impregnated carbon fiber piston seals for maximum trouble free life
- Anodized mounting bracket dissipates heat
- Integrated pressure switch, relays and IP55 (waterproof/dustproof) brushless fan cools electronics, motors and cylinder heads
- Over-pressure safety valve equipped
Documents: ARB Twin Motor Onboard 12V Air Compressor (CKMTA12)
ARB Twin Motor Onboard 12V Air Compressor (CKMTA12) Installation Guide
Compressor Technical Specifications Chart
Specifications: ARB Twin Motor Onboard 12V Air Compressor (CKMTA12)
|
Volts |
12V |
|
Width |
7.5 inch |
|
Height |
4 inch |
|
Length |
10.8 inch |
|
Weight |
17.4 lb |
|
Prop 65 |
No |
|
Max Amps |
68.6 |
|
IP Rating |
IP55 Ingress Protection |
|
Duty Cycle |
100% 60/0 |
|
Max Psi |
150 |
|
Air Flow 0PSI |
6.16 CFM |
|
Air Flow 29PSI |
4.68 CFM |
|
Design |
Onboard |
|
Warranty |
3-Year |
